Pepperl+Fuchs KFA6-SR2-EX1.W 103374

This isolated barrier is used for intrinsic safety applications. It transfers digital signals (NAMUR sensors/mechanical contacts) from a hazardous
area to a safe area.
The proximity sensor or switch controls a form C changeover relay contact for the safe area load. The barrier output changes state when the input
signal changes state. The normal output state can be reversed using switch S1. Switch S3 is used to enable or disable line fault detection of the
field circuit.
During an error condition, relays revert to their de-energized state and LEDs indicate the fault according to NAMUR NE44.

Email: anna at cwlyautomation dot com
Tel: +86 13667121125   whatsapp/ vk/ telegram also available
Company: Hongkong CW Green Tech Company

Pepperl+Fuchs Process Automation KFA6-SR2-EX1.W Isolator, Digital, K-System, Switch Amplifier, 1 Channel, 230VAC, 103374

Conductivity switch amplifier KFA6-ER-Ex1.W.LB
1-channel isolated barrier
230 V AC supply
Level sensing input
Adjustable range 1 kΩ and 150 kΩ
Relay contact output
Fault Relay Contact Output
Adjustable time delay up to 10 s
Minimum/Maximum Control
Line fault detection

Function of KFA6-ER-Ex1.W.LB
This isolated barrier is used for intrinsic safety applications. The device generates the AC measuring voltage to the conductive probe.

As soon as the affected Medium to be monitored by the electrodes, the change-over relay contact of the device.
