Festo EMMT-AS-60-S-LS-RMB 5242199 in stock

EMMT-AS-60-S-LS-RMB 5242199 Total mass moment of inertia of output
0.257 kgcm2
Nominal torque
0.6 Nm
Nominal rotary speed
3000 1/min

Email: anna at cwlyautomation dot com
Tel: +86 13667121125   whatsapp/ vk/ telegram also available
Company: Hongkong CW Green Tech Company

More Parameters about EMMT-AS-60-S-LS-RMB 5242199:
Ambient temperature
-15 °C ... 40 °C
Note on ambient temperature
Up to 80°C with derating of -1.5% per degree Celsius
Max. installation height
4000 m
Note on max. installation height
As of 1,000 m: only with derating of -1.0% per 100 m
Storage temperature
-20 °C ... 70 °C
Relative air humidity
0 - 90%
Conforms to standard
IEC 60034
Temperature class as per EN 60034-1
F
Max. winding temperature
155 °C
Rating class as per EN 60034-1
S1
Temperature monitoring
Digital motor temperature transmission via EnDat? 2.2
Motor type to EN 60034-7
IM B5
IM V1
IM V3
Mounting position
optional
Degree of protection
IP40
Note on degree of protection
IP40 for motor shaft without rotary shaft seal
IP65 for motor shaft with rotary shaft seal
IP67 for motor housing including connection components
Concentricity, coaxiality, axial runout to DIN SPEC 42955
